QIPANG CNC wire Cutting Machine cnc mental straightening and cutting machine high speed mental quick cut machine

1. Hydraulic 1-6mm wire straightening and cutting

2. automatic roller straightening and feeding machine

3. Flying shear quick cutting machine

4. Automatic precision straightening and cutting

The specific machine is made according to the customer's situation

Hydraulic 1-6mm wire straightening and cutting
automatic roller straightening and feeding machine
Flying shear quick cutting machine
Automatic precision straightening and cutting

Products Description

QIPANG CNC wire Cutting Machine cnc mental straightening and cutting machine high speed mental quick cut machine 1. Hydraulic 1-6mm wire straightening and cutting 2. automatic roller straightening and feeding machine 3. Flying shear quick cutting machine 4. Automatic precision straightening and cutting Products Description

Technical Data Sheet

NO.	Item.	Parameters and specifications
1	Model	1-2.5MM	2-4MM	3-5MM	3.5-6MM	4-7MM	5-8MM	6-10MM
2	Wire material	All kinds of wire
3	Wire diameter	Φ1.0-10mm（One machine is not enough）
4	Cutting length	Any length
5	Cutting length error	+-0.3mm
6	Number of material at a time	1pc
7	Out power	Traction 1.5kw with 1:10 planetary reducer, cut 1.5kw
8	Speed	Maximum 60m/ min -150m/ min （Stainless Steel ,50-60m/min, iron wire 70-80m/min）
9	Theoperating system	Inverter operation +PLC touch screen electronic CAM system
10	Operation mode	Automatic
11	surface appearance	No obvious pull, scratch, pressure and knurled scratch on the surface
12	Input voltage	380Vthree terms50Hz
13	machine size	Length1850wide780mmhigh1300mm
14	Weight	498KG
15	Pay-off machine weight	90KG
16	Pay-off machine size	The minimum diameter is 250mm and the maximum diameter is 500mm

Production workshop diagram

Related Product

Why Choose Us

Packaging & Delivery

FAQ

Q1: Are you a factory or trading company?
 We are a factory . We can promise you a short lead time and best price if you purchase our machine. We also have our own trading department.

Q2: How does the factory ensure products quality?
With Nearly 16 years experience in manufacturing winding machine, we have our own technology develop department and testing department.

Q3：How about your after-sale service?
We have a professional technology supporting team for your timely services. You can get the help you need in time by telephone, webcam, online chat (Google talk, Facebook, Skype). Please contact us once the machine has any problem. Best service will be offered.

Q4: What are your payment terms?
100%TT or prepaid 50% , balance 50% before shipping.

Q5: How can I get my order? How can I know you sent the goods?
We will send the goods by UPS, DHL, FedEx or sea shipment. After we sent the goods, we will give you the tracking number or other relative files for checking.

Q6 : Will you send the installed machine or machine parts?
We will install the machine and test the machine before delivery. And the machine can be used directly after receiving the machine
